Old 04-16-2009, 02:35 PM   #1
moenko   moenko is offline
Member

Join Date: Aug 2008
Location: Suffield, CT
Posts: 477
How many have changed their air intake?

I'm just curious - just installed the very simple version of the Caddman Air Filter Mod and was wondering how many of you have done that one (or any other, for that matter), and how it compares to stock. Impressions? If you use a TFI and know your settings, I'd be interested in that as well.



Login or Register to Remove Ads

Reply With Quote
Old 04-16-2009, 02:40 PM   #2
strobe   strobe is offline
Sr. Member

Join Date: Mar 2009
Posts: 1,200
How many have changed their air intake?

Did the Caddmann on both sides with the blockoff plate (left for looks only obviously), removed the ICS and marbled the reed valves.

Overall impressions have been good, noticeable performance difference. Mileage took a small hit if any, never tracked it that close before, but seems overall about even depending on how I ride though. Was not sure about the intake noise sucking air in, but got used to that. No TFI though, have a PCIII.
__________________
Cory
2013 Honda GL1800 Goldwing
2008 Kawasaki KLR 650 (for sale)
2007 Honda ST1300 (sold)
2005 Kawasaki Nomad (sold)
2004 Suzuki Hayabusa (sold)
http://www.strobel.ws
VBA #01021
VROC #29389

Reply With Quote
Old 04-16-2009, 02:54 PM   #3
reaper   reaper is offline
Advanced Member

reaper's Avatar

Join Date: Nov 2008
Location: St. Augustine, FL
Posts: 591
How many have changed their air intake?

Did the Caddman, TFI, Debaff.
I used a rubber stopper instead of marble
MPG's about the same.
MBA dyno (My Big A$$) says performance improved
__________________
Doug
08 1600 Nomad FI Metallic Ocean Blue / Neutron Silver

Web Slinger's Speedo face, Chuckster's Air Kit, Jay's LED Tail light, dshelly's throttle mod, Kuryakan Deep Bezel lens, Headlight Modulator, Kuryakan Run/Brake/Turn, DWG 2" speakers and amp, Stebel Air Horn

Fire & Iron, Red Knights, ROK, VBA, VRA, VROC, IAFF

Reply With Quote
Old 04-16-2009, 03:10 PM   #4
cactusjack   cactusjack is offline
Mega-Contributor

cactusjack's Avatar

Join Date: Sep 2007
Location: Where it doesn't snow...ever!
Posts: 21,926
How many have changed their air intake?

I did the Caddman on the right side, then added Chuckster's 7" aluminum backing plate and 7"x2" K&N air filter.

ICS solenoids - removed
Vacuum tubes/hoses - removed (capped at manifold)
Crankcase breather vented back through the intake
Reed valve hose - plugged with rubber stopper.

I have removed the air filter housing and backing plate from the left side. Still deciding what to do over there. I would prefer to keep the crossover tube and just cover it with something.

I have a Cobra FI2000R with the pots currently set at 3-5-0.
__________________
Scott "Cactusjack" Hanks
VBA #00105
H.O.G. #4250060

2011 H-D Ultra Limited 103ci



:: 2011 HD Electra Glide Ultra Limited w/Stage 1 ::


Rallies: Mesquite '08|Custer '09|Cortez '10|Crescent City '11|Kanab '12|Antlers '12|Estes Park '13|Antlers '13|Orofino '14|The Dalles '17


Reply With Quote
Old 04-16-2009, 07:13 PM   #5
paul   paul is offline
Sr. Member

paul's Avatar

Join Date: Jan 2008
Location: magnolia, tx
Posts: 1,500
How many have changed their air intake?

Have VH pipes, did the thunder kit w/exposed k&n right side only operative. TFI plug and play. Solenoids gone, reeds gone, all plumbing blocked off and cleaned up. Actually, just got through doing some more 'tuniing' and she runs like a scalded dog. Big difference in 'grab a handfull' acceleration. Just rolling on at 60 in 5th (2200 rpm mas or menos) is much improved. Gas mileage, about 38 from 40. Maybe with a lighter hand, it would be better, but where's the fun in that!? ???
__________________
The beatings will stop when morale improves.



Login or Register to Remove Ads

Reply With Quote
Old 04-16-2009, 08:33 PM   #6
Scoot   Scoot is offline
Advanced Member

Scoot's Avatar

Join Date: Aug 2007
Location: Selma, Alabama
Posts: 878
How many have changed their air intake?


Quote:
Originally Posted by hmsregalnadness
Have VH pipes, did the thunder kit w/exposed k&n right side only operative. TFI . Solenoids gone, reeds gone, all plumbing blocked off and cleaned up. Actually, she runs like a scalded dog. Big difference in 'grab a handfull' acceleration.

+1 yep had this for years
__________________
2002 1500
VBA #00077
_____________________
2013 Ultra Classic (Pearl White)

Reply With Quote
Old 04-16-2009, 08:40 PM   #7
paul57   paul57 is offline
Jr. Member

Join Date: Jan 2008
Location: Houston,BC
Posts: 31
How many have changed their air intake?

Have Cobra pipes,Chucksters plate with a K&N left the ICS hooked up,blocked the left side.Put on a TFI set at 2 4 1&9 . Took the reed valves off.Runs awesome ,lots of power alone or with my wife.Uphill in 5th gear roll on the throttle and it just goes

Reply With Quote
Old 04-16-2009, 09:23 PM   #8
caddman11   caddman11 is offline
Advanced Member

caddman11's Avatar

Join Date: Feb 2008
Location: Northwest Indiana
Posts: 890
How many have changed their air intake?

OK, I did the one side caddmann mod today and changed it back--to much racket. Didn't have a whole lot of time because I want to ride in the morning and it got pretty late installing a Clearview windshield. More on that later.

The noise of the solenoids was unreal on deceleration so until I figure out what to do with those, I going to keep the cover on. Dooley pipes with a Fi2000 set at default and running very rich, so I got to work on that one too. If only I could retire~~~~~~

Reply With Quote
Old 04-16-2009, 09:47 PM   #9
dogdoc   dogdoc is offline
Top Contributor

Join Date: Jul 2007
Posts: 5,263
How many have changed their air intake?

TFI tweaked just right, caddman mod kit on the right, ISC unplugged, marble in the tube, left side balnced but sucking no air, V&H pipes and she is running lke a scalded dog. You will take a hit in mpg no matter what others will tell you. Your mpg will drop 2-4 for the extra hp. At least Im honest. :-)

Reply With Quote
Old 04-17-2009, 08:53 AM   #10
mikesth   mikesth is offline
Member

Join Date: Nov 2007
Location: Katy Texas
Posts: 478
How many have changed their air intake?


Quote:
Originally Posted by cactusjack
I did the Caddman on the right side, then added Chuckster's 7" aluminum backing plate and 7"x2" K&N air filter.

ICS solenoids - removed
Vacuum tubes/hoses - removed (capped at manifold)
Crankcase breather vented back through the intake
Reed valve hose - plugged with rubber stopper.

Still deciding what to do on left side. I would prefer to keep the crossover tube and just cover it with something.

I have a Cobra FI2000R with the pots currently set at 3-5-0.
Same as my bike just add the V&H pipes - Good job CJ!

Reply With Quote
Old 04-17-2009, 06:59 PM   #11
goldstar225   goldstar225 is offline
Member

Join Date: Sep 2008
Location: Cabot, Arkansas
Posts: 211
How many have changed their air intake?

I bought my bike used and it came with a Hypercharger installed. I'm dumping the Hypercharger and going with Chuckster's 7" plate. I figure the performance will be the same and I won't have the Hypercharger limiting my access to the brake pedal or taking skin off of my shin.

(I was previously going to go back to the stock air system until my shop told me how much they would charge me in labor)

Reply With Quote
Old 04-17-2009, 08:37 PM   #12
borto1990   borto1990 is offline
Member

borto1990's Avatar

Join Date: Jan 2009
Location: grand rapids, mi
Posts: 475
How many have changed their air intake?

I did chucksters plate, coasters, removed solenoids, PCIII, "ultimate" baffle with the V&H. seems better every time I ride. got 34 MPG last tank

Reply With Quote
Old 04-17-2009, 09:24 PM   #13
redjay   redjay is offline
Top Contributor

Join Date: Feb 2008
Location: Ontario
Posts: 7,016
How many have changed their air intake?

I got 34.7 mpg today. Gutted mufflers and goatbelly, Caddman right side, K&N replacing the stocker, TFI set at 4.30-6-1-9. Open the throttle in 4th and 5th and hang on !

I got 38 mpg last weekend without the Caddman mod and TFI set at 3-6-1-9.

Reply With Quote
Old 04-18-2009, 10:22 AM   #14
voyager   voyager is offline

voyager's Avatar

Join Date: Sep 2007
Location: Stony Plain, Alberta
Posts: 694
How many have changed their air intake?

Removed the entire intake, left the left side bare for now, and installed a Thunder Ram Air intake with the K&N filter, TFI and Cobra Slash Cuts. Setting of the TFI 3.30-6.0-1.0-9.0 . Only thing I have to get used to now is the increase in air volume noise going through the intake, makes for a much different noise than the muffled stock arrangement.

__________________
Travel is fatal to prejudice, bigotry, and narrow-mindedness, and many of our people need it sorely on these accounts.........Mark Twain.

Reply With Quote
Old 04-20-2009, 01:38 PM   #15
moenko   moenko is offline
Member

Join Date: Aug 2008
Location: Suffield, CT
Posts: 477
How many have changed their air intake?

Very interesting results - thanks folks!
